FX-350/351 Series Programming Manual
35
If the list to be unbypassed is shown, just press Enter to complete the unbypassing. Otherwise, you may unbypass
the devices one, two or more at a time.
If you are attempting to unbypass items that are already unbypassed you will get an “Already un-bypassed”
message.
Otherwise, if the exclamation is not used, then there will be individual confirmation.
At the end of the un-bypass operation or if the exclamation is used, the message will be . . .
OPERATION MENU/7. AUX DISC
The auxiliary disconnect operation is performed by the following the steps below. If the auxiliary relays are
connected the user is prompted to disconnect the relays.
After the confirmation the auxiliary relays are disconnected and the information message is displayed that the
auxiliary relays are disconnected.
If the auxiliary relays are already disconnected the user is prompted to reconnect the relays.
After the confirmation the auxiliary relays are reconnected and the information message is displayed that the
auxiliary relays are reconnected.
OPERATION MENU/8. TEST DIALER
Special function is provided to test the dialer operation. This function can manually test both the phone line L1 and
L2 and also reset the dialer where all the events to be reported in the queue are cleared and the dialer status is
reset.
Lp: x Addr:xxx
Un-bypass? Y/N
Lp: x Addr:xxx
Already un-bypassed
Device/circuit
unbypassed
Done...
Aux relays connected
Disconnect ?Y/N
Aux relays
disconnected
Aux rly disconnected
Reconnect ?Y/N
Aux relays
Reconnected
---Dialer test ----
1. L#1 manual test
2. L#2 manual test
3. Reset dialer
