[ III Specification ]
- 6 -
HWE1804A GB
2. Electrical parts specifications
model
Symbol
PEFY-P36, 48NMHU-E-OA PEFY-P72NMHU-E-OA PEFY-P96NMHU-E-OA
Parts name
Outlet air temperature
thermistor
TH21 Resistance 0°C/15kΩ, 10°C/9.6kΩ, 20°C/6.3kΩ, 25°C/5.4kΩ, 30°C/4.3kΩ, 40°C/3.0kΩ
Liquid pipe thermistor TH22 Resistance 0°C/15kΩ, 10°C/9.6kΩ, 20°C/6.3kΩ, 25°C/5.4kΩ, 30°C/4.3kΩ, 40°C/3.0kΩ
Gas pipe thermistor TH23 Resistance 0°C/15kΩ, 10°C/9.6kΩ, 20°C/6.3kΩ, 25°C/5.4kΩ, 30°C/4.3kΩ, 40°C/3.0kΩ
Inlet air temperature
thermistor
TH24 Resistance 0°C/15kΩ, 10°C/9.6kΩ, 20°C/6.3kΩ, 25°C/5.4kΩ, 30°C/4.3kΩ, 40°C/3.0kΩ
Fuse FUSE 250 VAC 6.3A
Fan motor
(with inner thermostat)
MF1, 2
8-pole, output 244W
SIC-101CW-D8244-4
10-pole, output 375W
KMUC4E2MW or KMUC4E3MW
Linear expansion valve LEV 12 VDC Stepping motor drive
Power supply terminal
bed
TB2 (L, N, ) 250V 20A
Transmission terminal
bed
TB5
TB15
(M1, M2, S) 250V 20A
(1, 2) 250V 15A
