36
-
(3) Ceiling suspended type (FDEN)
(a) Single type
Model FDENVA151HEN1R
Model
Item
FDENVA151HEN1R
FDENA151R FDCVA151HENR
Nominal cooling capacity
(1)
kW
3.8 [1.8~4.7]
Nominal heating capacity
(1)
kW
4.5 [2.0~5.4]
Power source 1 Phase, 220-240V 50Hz/220V 60Hz
Operation data
(3)
Cooling power consumption kW
1.18/1.18
Running current (Cooling) A
5.3/5.5
Power factor (Cooling) %
97/98
Heating power consumption kW
1.32/1.32
Running current (Heating) A
5.9/6.2
Power factor (Heating) %
97/97
Inrush current (L.R.A) A
5
Noise level dB(A)
Powerful mode Hi:42 Me:39 Lo:38
Mild mode Hi:39 Me:38 Lo:37
48
Exterior dimensions
Height × Width × Depth
mm 210 × 1070 × 690 595 × 780 (+67) × 290
Net weight kg 30 40
Refrigerant equipment
Compressor type & Q’ty
–
5CS102XFD × 1
Starting method – Direct line start
Heat exchanger
Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg –
1.55 [Pre-charged up to the piping length of 30m]
Refrigerant oil
r
–
0.48 (RB68A)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty
Multiblade centrifugal fan × 2 Propeller fan × 1
Motor W 30 × 134 × 1
Starting method Direct line start Direct line start
Air fl ow CMM
Powerful mode Hi:12 Me:11 Lo:9
Mild mode Hi:11 Me:9 Lo:7
41
Outside air intake
Unavailable –
Air filter, Q’ty Plastic net (washable) × 2 –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Operation switch
Wireless remote control switch (Optional: RCN-E1R)
Wired remote control switch (Optional: RC-E1R)
– (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment
Internal thermostat for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Anomalous discharge temperature protection.
Installation data
Refrigerant piping size
mm
(in)
Liquid line: φ6.35 (1/4″) Gas line: φ12.7 (1/2″)
Connecting method Flare piping
Drain hose
Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
Notes (1) The data are measured at the following conditions.
Item
Operation
Indoor air temperature Outdoor air temperature
Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
ISO-T1
Heating 20˚C – 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
To Next Page
