58
-
(4) Satellite ducted type (FDUM)
(a) single type
Model FDUMVA201HEN2R
Model
Item
FDUMVA201HEN2R
FDUMA202R FDCVA201HENR
Nominal cooling capacity
(1)
kW
5.0 [2.2~5.6]
Nominal heating capacity
(1)
kW
5.4 [2.5~6.3]
Power source 1 Phase, 220-240V, 50Hz/220V, 60Hz
Operation data
(3)
Cooling power consumption kW
1.53/1.53
Running current (Cooling) A
6.8/7.1
Power factor (Cooling) %
98/98
Heating power consumption kW
1.58/1.58
Running current (Heating) A
7.0/7.3
Power factor (Heating) %
98/98
Inrush current (L.R.A) A
5
Noise level dB(A) Hi:34 Me:31 Lo:28 48
Exterior dimensions
Height × Width × Depth
mm 299 × 750 × 635 595 × 780 (+67) × 290
Net weight kg 34 40
Refrigerant equipment
Compressor type & Q’ty
–
5CS102XFD × 1
Starting method – Direct line start
Heat exchanger
Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg –
1.55 [Pre-charged up to the piping length of 30m]
Refrigerant oil
r
–
0.48 (RB68A)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty
Multiblade centrifugal fan × 2 Propeller fan ×1
Motor W
55 × 1
34 × 1
Starting method Direct line start Direct line start
Air fl ow (Standard) CMM Hi:14 Me:12 Lo:11 41
Available static pressure
Pa
Standard: 50, Max: 85
–
Outside air intake
––
Air filter, Q’ty – –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Operation switch
Wired remote control switch (Optional : RC-E1R)
Wireless kit (Optional : RCND-KIT-HER)
– (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment
Internal thermostat for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Anomalous discharge temperature protection.
Installation data
Refrigerant piping size
mm
(in)
Liquid line: φ6.35 (1/4″) Gas line: φ12.7 (1/2″)
Connecting method Flare piping
Drain hose
Connectable with VP25 (I.D. 25mm, O.D. 32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Filter kit (UM-FL1E)
Notes (1) The data are measured at the following conditions.
Item
Operation
Indoor air temperature Outdoor air temperature
Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
ISO-T1
Heating 20˚C – 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
