Mitsubishi Heavy Industries FDURA501 User Manual

-
107
-
• Pattern 3
Multiple longitudinal and vertical and horizontal rows installed
Unit: mm
• Pattern 4
Multiple longitudinal and vertical and horizontal rows installed
800
800
800
100
100
750
750
750
1500
800
800
800
500
500
1500
H=1000 or less
H=1000 or less
Front
Front
H=1500 or less
H=1500 or less
Front
Front
With no height restrictions
With no height restrictions
With no height restrictions
H=1000
or less
H=1000
or less
H=1000
or less
750
With no height restrictions
H=1000
or less
(c) Notabilia for installation
1) Anchor bolt positions
a)
Use four anchor bolts (M12) to fix an outdoor unit’s anchoring legs at all times. Ideally, an anchor bolt should protrude 20mm.
1350
850
720 594 8585 726 764
20
Unit
Anchor bolt positions
(

mark)
Unit : mm
b) Base
• Install the unit so that it does not vibrate and doesn’t make noise. Make sure the base is strong and that it is installed level.
• Provide a foundation that is at least as wide as the area shown by the shaded portion in the diagram above (wider than the
width between the front surface of the anchoring legs of the outdoor unit).
Unit leg
Foundation
