(3) Operation chart
The Multi series is a system that allows for different models and capacities of indoor units to be combined so the individual
operating characteristics of the indoor and outdoor are provided. Use the procedure shown in Item (c) to calculate the combined
operating characteristics.
(a) Operating characteristic of outdoor unit
Cooling input
Heating input
Cooling running current
Heating running current
Inrush current (L.R.A)
Cooling power factor
Heating power factor
(230 V)
Item
Model
FDCA301HEN
2.15
2.06
9.8
9.5
63
95
94
3.31
3.08
15.3
13.8
97
94
97
FDCA401HEN
kW
A
A
%
Cooling input
Heating input
Cooling running current
Heating running current
Inrush current (L.R.A)
Cooling power factor
Heating power factor
(400 V)
Item
Model
FDCA301HES
2.15
2.06
3.6
3.5
34
86
85
FDCA401HES
3.16
2.98
5.5
5.1
46
83
84
4.29
3.58
7.4
6.1
67
84
85
FDCA501HES
4.35
4.44
7.2
7.0
77
87
92
FDCA601HES
kW
A
A
%
Cooling input
Heating input
Cooling running current
Heating running current
Inrush current (L.R.A)
Cooling power factor
Heating power factor
(400 V)
Item
Model
FDCA801HES
6.79
6.69
11.0
11.0
58
86
85
7.29
7.24
11.4
11.6
58
89
87
FDCA1001HES
kW
A
A
%
Note (1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(b) Operating characteristic of indoor unit
Notes (1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(2) The values shown in the above table are common to both cooling and heating operations.
Item
Model FDT Series
FDT Series
(230 V)
Power input (kW)
Running current (A)
0.06
0.3
0.07
0.3
0.13
0.6
0.15
0.7
151 201 251 301 401 501
Item
Model FDEN Series
Power input (kW)
Running current (A)
0.05
0.2
0.10
0.4
0.13
0.5
0.15
0.6
151 201 251 301 401 501
FDEN Series
(230 V)
