23
-
Air outlet
Air inlet grille
VIEW A
VIEW B
VIEW C VIEW D
Decorative Panel
700 or less
(Max. Drain up)
Drain hose
(Accessories)
(Local setting)
Hole for wiring
840
212
95
45
35 270
187
137
332
637
422
420
310
267
950
630
295~325
122
100
25
55
123
140
80 100
160 43
60
140
140 52
ø15.88(5/8")
A
6-ø4
4-ø4
860~890(Ceiling hole size)
780(Suspension bolts pitch)
675(Suspension bolts pitch)
Control box
Fresh air
opening for
ducting
Exhaust air
opening for
ducting
Control box
Gas piping
ø9.52(3/8")
Liquid piping
or more
Lug for
suspension bolts
Space for installation and service
Obstacle
Holes for
tapping screws
Holes for
tapping screws
Holes
Holes
Suspension bolts
B
D
C
Drain
(Connectable with VP25)
1000
or more
2500 or more
Model FDTA301
unit : mm
