Mitsubishi FREQROL-U100 User Manual

Connection of main circuit terminals
Use a
small minus screwdriver (with
blade width 2.5 to 3 mm).
It is introduced in the upper slot@ and
it's blade holds the spring open so that
the stripped power supply wire can be
introduced into the terminal @.
Withdraw the screwdriver, the conductor
is clamped.
Connection of control circuit terminal
Insert a
small minus screwdriver
(with blade width 2.5 to 3 mm) into the
right hole <9, and insert the stripped
wire into @ while pressing the
screwdriver in the direction of the
arrow. Remove the screwdriver when
the
wire has been inserted.
(Note) Use a
small flat-blade screwdriver (blade width 2.5 to 3mm).
