+Example of noise countermeasures
Motor
Sensor
Use a s-ecre cable for the
motor power cable, and use
one wire for the grounding.
Install a filter (FR·BSFOl)
on the inverter
output side.
Do not ground the shield,
but instead
connllGt to the
common wire for the signals.
Use twisted pair shieldwires.
lower carrier
frequency
Do not
dirllGtly ground
to the control panel.
~~ :~t~~e~];e.9rOund '-_"'- -'tJ
Separate the inverter unit", .... _
power cables and sensor
circuit by
30cm or more
(at least lDem).
Install a filter
(FR.BSFOl) on the
Power _ inverter input side.
supply-o
Install a fHur
(FR. elF) on the
inverter input side
Control
panel
-42-
