SYSTEM OPERATION
FOUR-WHEEL ANTI-LOCK BRAKE SYSTEM (4ABS)
35B-10
SERVICE DATA OUTPUT
.
ACTUATOR TEST
SYSTEM OPERATION
M2351004000114
In terms of operation, the system is basically the
same as that of the LANCER.
SCAN TOOL
DISPLAY
ITEM NO. CHECK ITEM DISPLAY TEXT
OR UNIT
FR SNSR 11 Front-right ABS sensor km/h or mph
FL SNSR 12 Front-left ABS sensor
RR SNSR 13 Rear-right ABS sensor
RL SNSR 14 Rear-left ABS sensor
BATT. VOLTAGE 21 ABS-ECU power supply voltage V
29 Parking brake switch ON/OFF
32 Longitudinal G-sensor V
STOPLIGHT SW 36 Stoplight switch ON/OFF
37 Steering angular velocity sensor straight ahead position
memory
ON/OFF
71 Lateral G-sensor V
74 Steering angular velocity sensor (ST-N) OFF/ON
75 Steering angular velocity sensor (ST-1)
76 Steering angular velocity sensor (ST-2)
86 Steering angle
° or OFF (when the
steering angle is
straight ahead
position)
NO. ITEM PARTS TO BE ACTIVATED
01 Solenoid valve for front-left wheel Solenoid valves and pump motors in the hydraulic
unit (simple inspection mode)
02 Solenoid valve for front-right wheel
03 Solenoid valve for rear-left wheel
04 Solenoid valve for rear-right wheel
