AERO PARTS
EXTERIOR
51-4
AERO PARTS
GENERAL INFORMATION
M2510000100558
• An under cover, a side air dam and a rear spoiler
have been adopted for better aerodynamic per-
formance and an appealing look.
• The rear spoiler has two types. Type A is stan-
dard, and type B is optional equipment. The
model without a spoiler is offered as an option.
CONSTRUCTION DIAGRAM
UNDER COVER
The large undercover with venturi ducts improve
downforce characteristics and drivetrain cooling per-
formance.
REAR SPOILER
• For type A <standard>, the use of carbon fiber for
the rear spoiler makes the unit more rigid and
thinner for minimum drag that produces efficient
downforce.
• For type B <option>, a rear spoiler incorporating
high-mounted stop light has been adopted.
AC210652
FRONT BUMPER
UNDER COVER
AB
AC212236
SIDE AIR DAM
REAR SPOILER
TYPE A
TYPE B
AB
HIGH MOUNTED
STOP LIGHT
To Next Page
