Page #46 background image
3 - 25 3 - 25
MELSEC-
A
3 SPECIFICATIONS
3.7.9 Setting data (2 occupied stations: Address RWrn+4, common to 4 and 8 occupied
stations (4 occupied stations 2 modules): Address RWrn 7)
The setting statuses of the switches for occupied station number setting, transmission
speed setting, point mode setting, test mode and data link last station number are
stored.
When 2 stations are occupied, the setting data of CC-Link/LT are stored into
RWrn+4.
When 4 or 8 stations (4 occupied stations
2 modules) are occupied, the setting
data of CC-Link/LT are stored into RWrn
7.
Bit Name Description
b0 to b1
Number of occupied
stations
Setting statuses of the CC-Link side switches SW1, SW2
for operation setting
00: 2 occupied stations 01: 4 occupied stations,
10: 8 occupied stations (4 occupied stations
2 modules)
11: Setting prohibited
b2 to b3
Transmission speed
setting
Setting statuses of the CC-Link side switches SW8, SW9,
SW10 for operation setting
00: 156kbps 01: 625kbps
10: 2.5Mbps 11: Setting prohibited
b4 to b5 Point mode setting
Setting statuses of the CC-Link side switches SW4, SW5
for operation setting
00: 8-point mode 01: 4-point mode,
10: 16-point mode 11: Setting prohibited
b6 Test mode
Setting status of the CC-Link side switch SW3 for operation
setting
0: Under usual conditions
1: At self-loopback test execution time
b7 Not used
b8 to b13
Data link last station
number
The last station number of the remote station that can
perform a data link is stored.
b14 to b15 Not used
0: Switch OFF
1: Switch ON
POINT
The values of this remote register change depending on the occupied station
number setting, point mode setting and last station number setting.
If any CC-Link/LT remote station connected has a station number setting greater
than the value of the data link last station number, an error of station outside
control range occurs.
