2.3 Confirming Serial No. and Function Version
The serial No. and function version of the CPU module can be confirmed on the rated
plate and GX Developer's system monitor.
(1) Confirming the serial No. on the rated plate
The rated plate is situated on the side face of the CPU module.
(2) Checking on the front of the module
The serial number written on the rating plate is displayed on the front (at the bottom)
of the module.
Figure 2.4 The rated plate
Figure 2.5 CPU module front display
MADE IN JAPAN
SERIAL
MODEL
PASSED
function version
Serial No. (first 5 digits)
Standard symbol for
conformance is described.
080910000000000-A
090911090910001-B
Serial No.
PULL
Q S 0 0 1 C P U
A L I V E
R U N
E R R.
T E S T
U S E R
B A T.
U S B
