CHAPTER5 POWER SUPPLY MODULE
This section describes the specifications of the power supply modules applicable for the
PLC system and how to select the most suitable module.
5.1 Specifications
Table5.1 shows the specifications of the power supply modules.
Table5.1 Power supply module specifications
Item
Performance Specifications
QS061P-A1 QS061P-A2
Base loading position QS series power supply module loading slot
Applicable base unit QS034B
Input power supply
100 to 120VAC
(85 to 132VAC)
200 to 240VAC
(170 to 264VAC)
Input frequency
50/60Hz 5%
Input voltage distortion factor
Within 5% ( Section 5.2)
Max. input apparent power 125VA
Inrush current
20A within 8ms
*4
Rated output
current
5VDC 6A
Overcurrent
protection
*1
5VDC 6.6A or more
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
Efficiency 70% or more
Allowable momentary power
failure period
*3
Within 20ms
Dielectric withstand voltage
Across inputs/LG and outputs/FG
1780VAC rms/3 cycles (2000 m (6562 ft.))
Across inputs/LG and outputs/FG
2830VAC rms/3 cycles (2000 m (6562 ft.))
Insulation resistance
Across inputs/LG and outputs/FG, across inputs and LG, across outputs and FG 10M
or more by insulation resistance tester
Noise durability
• By noise simulator of 1500Vp-p noise voltage, 1 s noise width and 25 to 60Hz noise
frequency
• Noise voltage IEC61000-4-4, 2kV
Operation indication LED indication (Normal: On (green), Error: Off)
Fuse Built-in (Unchangeable by user)
+10%
-15%
+10%
-15%
