Replacement of light bulbs
9-32 Vehicle care and maintenance
4. Turn the bulb counterclockwise to remove
it.
5. To install the bulb, perform the removal
steps in reverse.
N00943701569
1. Open the liftgate.
(Refer to “Liftgate” on page 5-27.)
2. Remove the screws (A) that hold the light
unit.
3. Move the light unit toward the rear of the
vehicle to unfix the notch (B) and pin (C).
4. Turn the socket counterclockwise to
remove it.
5. Remove the bulb from the socket as fol-
lows.
When refitting each of the clips, first insert
part (E) of the clip into the hole and then
press part (F) into it.
Rear combination lights
D- Back-up light
E- Rear turn signal light
F- Rear side-marker light, and tail and
stop light (LED) - Do not touch the
socket because replacing this light is
carried out by an authorized Mitsubishi
Motors dealer or a repair facility of
your choice.
The rear side-marker light, and tail and stop
light use an LED instead of the bulb.
Check with an authorized Mitsubishi Motors
dealer or a repair facility of your choice
when the light needs to be repaired or
replaced.
