The engine model and serial number are
stamped on the cylinder block as shown in
the illustration.
N01148100616
The tire and loading information placard is
located on the driver’s door sill.
N01148200242
The certification label is located on the
driver’s door sill.
N01147501649
Engine model/serial number
*- Front of the vehicle
Tire and loading information
placard
Certification label
Vehicle dimensions
Overall length 149.4 in (3,795 mm)
Overall width 65.6 in (1,665 mm)
Overall height 59.4 in (1,510 mm)
Wheel base 96.5 in (2,450 mm)
