Cargo area cover*
E00715500551
To use
1. Draw out the cover retracted by spring and in-
sert it in the mounting grooves (A).
2. Remove the cover from the mounting
grooves, and the cover will roll back into the
retracted position.
NOTE
l
Do not put luggage on the cargo area cover.
To change
There are 2 installation holes (B) for the cargo area
cover.
1. Move one of the sliders (C) towards the in-
side of the vehicle, and fit the tab (D) into
the installation hole that is to be used. Move
the opposite slider in the same fashion.
2. After changing the position, gently shake the
entire cargo area cover to make sure it is se-
curely retained.
NOTE
l
If the rear seat seatbacks make contact with
the cargo area cover, move back the cargo
area cover.
The cargo area cover could break if it sup-
ports the seatback of the rear seat.
To remove
1. Wind up the cargo area cover.
2. Move one of the sliders (C) towards the in-
side of the vehicle and lift it to remove the
cargo area cover.
To fit the cargo area cover, follow the removal
steps in reverse. Gently shake the entire cargo area
cover after fitting it to make sure it is securely re-
tained.
For pleasant driving
5-93
