1 - 1
1
OVERVIEW
CHAPTER1 OVERVIEW
This manual describes the programs, I/O number assignment method, functions, devices,
and other specifications of the Q series CPU modules ( (1) below).
Refer to the following manual, for the other specifications such as the power supply
modules, base units, extension cables, memory cards, and batteries.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
(1) CPU modules corresponding to the description of this manual
The CPU modules described in this manual are as shown in Table1.1.
Table1.1 List of CPU modules corresponding to the description of this manual
CPU module Model name
Basic model QCPU Q00JCPU, Q00CPU, Q01CPU
High Performance model QCPU
Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU,
Q25HCPU
Process CPU Q02PHCPU, Q06PHCPU, Q12PHCPU, Q25PHCPU
Redundant CPU Q12PRHCPU, Q25PRHCPU
Universal model QCPU
Q02UCPU, Q03UDCPU, Q04UDHCPU, Q06UDHCPU,
Q13UDHCPU, Q26UDHCPU, Q03UDECPU,
Q04UDEHCPU, Q06UDEHCPU, Q13UDEHCPU,
Q26UDEHCPU
To Next Page
