3
SEQUENCE PROGRAM CONFIGURATION AND
EXECUTION CONDITIONS
3.9 Numeric Values which can be Used in Sequence Programs
3.9.1 BIN (Binary Code)
3 - 83
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
POINT
To each bit of each register, a 2
n
value is assigned.
Note that an unsigned (no sign) binary number (0 to 65535) cannot be used since
the most significant bit is used for discrimination of sign (positive or negative).
1) When most significant bit is "0"...Positive
2) When most significant bit is "1"...Negative
To Next Page
