APPENDICES
Appendix 4 Functions Added or Changed Due to Version Upgrade
Appendix 4.2 High Performance model QCPU Upgrade
App - 106
9
Parameters
10
Device Explanation
11
CPU Module Processing
Time
12
Procedure for Writing
Program to CPU ModuleAppendicesIndex
Appendix 4.2 High Performance model QCPU Upgrade
(1) Specification comparison
: Usable/compatible, : Unusable/incompatible
TableApp.43 Specification comparison
Specifications
First 5 digits of Serial No. of CPU Module
Function Version A Function Version B
02091 or
earlier
02092 or later
“02112” or
later
03051 or later 04012 or later
Standard RAM capacity
Q02CPU 64kbyte
Q02HCPU 64kbyte 128kbyte
Q06HCPU 64kbyte 128kbyte
Q12HCPU 64kbyte 256kbyte
Q25HCPU 64kbyte 256kbyte
CPU shared memory
Extended life battery SRAM card
Compatibility with 2Mbyte SRAM card
To Next Page
