Mitsubishi Q06HCPU User Manual

3
SEQUENCE PROGRAM CONFIGURATION AND
EXECUTION CONDITIONS
3.7 Data Clear Processing
3 - 71
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(2) Device latch specification
Make the latch specification (latch range setting) for each device in the device setting
of the PLC parameter dialog box of GX Developer.( Section 6.3(5))
(a) Latch range setting
The latch range can be set by the following 2 methods using GX Developer.
1) Latch clear operation enable (Latch (1) first/last)
Set the latch range that can be cleared by the latch clear operation performed
by the RESET/L.CLR switch
Note3.38
or the remote latch clear.Note36
2) Latch clear operation disable (Latch (2) first/last)
Set the latch range that cannot be cleared by the latch clear operation
performed by the RESET/L.CLR switch
Note3.38
or the remote latch clear.
(b) Clearing device data set to latch clear operation enable
• Latch clear operation by the RESET/L.CLR switch
Note3.38
Note37
• Clear operation by the remote latch clear( Section 6.6.4)from GX
Developer
(c) Clearing device data set to latch clear operation disable
The device data set to latch clear operation disable can be cleared only by the
instruction or the clear operation using GX Developer.
1) Clearing by instruction
Reset the device data using the RST instruction or transfer K0 using the MOV/
FMOV instruction.
QCPU (Q Mode)/QnACPU Programming Manual (Common Instructions)
2) Clearing by GX Developer
Choose [Online] [Clear PLC memory] and execute device memory all clear
(including latch).
POINT
1. When the start mode of the Redundant CPU is the hot-start mode, the data
outside the latch range are also held.
(Except some devices such as the step relay and index register.).
2. For the Universal model QCPU, the scan time is prolonged when the device is
latched. When latching a device, consider the prolonging scan time.
( Section 10.1.2 (11) )
Remark
Refer to the following manual for the operation of GX Developer.
GX Developer Operating Manual
Note36
Note37
Basic
Universal
UD
Note3.38
Note3.38
The Basic model QCPU and Universal model QCPU cannot perform latch clear by switch
operation.
Basic
Note3.38
Universal
UD
Note3.38
Basic
Universal
UD
Note3.38
Note3.38
Basic
Note3.38
Universal
UD
Note3.38
