39
PRESET MENU
To enter the Sub 37’s PRESET EDIT MENU press and hold the PRESET button for one second. This
menu contains per-preset parameters that are not represented by the front panel knobs and buttons.
The top right of the LED display will indicate which page you are on, followed by a decimal point, and
then which parameter line you currently have selected. Use the buttons to choose a parameter
for editing, and the FINE TUNE knob to scroll through a selected parameter’s available options.
NOTE: You can also use the CURSOR button to select a parameter and the buttons to step
through the selected parameter’s available options. To exit a parameter, simply press CURSOR again.
If more than one page of parameters exists, continuing to press the button will take you through
the additional parameters and pages. If the MENU WRAP parameter (GLOBAL MENU) is OFF, the
button will stop working at the last parameter of the last page.
SUB MENU PARAMETERS
Some parameter types have multiple sub parameters, which are indicated by “>>”. If you have one of
these menu titles highlighted, you can jump to the sub menu by pressing the CURSOR button. To exit a
sub menu highlight the “(BACK)<<” parameter and press the CURSOR button. This will take you back
to the previous menu.
PRESET EDIT 1.X
ARPEGGIATOR >>
SEQUENCER >>
FILTER EG >>
AMP EG >>
KB TRANSPOSE: -12 ... OFF ... +12
KB PRIORITY: LOW, HIGH, LAST
BEND UP: +0 ... +24
BEND DOWN: -0 ... -24
BEND DEST: NONE, OSC1, OSC2, BOTH
PRESET VOL: OFF ... 100%
PRESET EDIT 2.X
1
2
FILTER EG
GATE SRC: BOTH, NOTES, EXT
EXP. ATTACK: ON, OFF
CLOCK DIV: SEE PAGE 52
SEQUENCER
MOD DST: SEE PAGE 51
SEQ MOD AMT: OFF ... 100%
SEQ MOD ONLY: OFF, ON
MODWHL CTRL: OFF, ON
RATCHET CNT: 1 - 8
AMP EG
GATE SRC: BOTH, NOTES, EXT
EXP. ATTACK: ON, OFF
CLOCK DIV: SEE PAGE 52
ARPEGGIATOR
GATE LENGTH: OFF ... 100%
CLOCK DIV: SEE PAGE 52
SWING: 0.0% ... 100.O%
STEP 1 RESET: OFF, ON
END NOTES: ONCE, TWICE
To Next Page
