CONTROLLERS MENU
Pressing this button takes you to the MOD 1 or MOD 2 CONTROL MENU on the LED display screen. Here
you can determine the amount of effect that the MODULATION wheel, VELOCITY, AFTERTOUCH, and
an assignable CONTROLLER 4, have on the modulation destinations. Use the buttons to choose a
parameter for editing, and the FINE TUNE knob to scroll through a selected parameter’s available options.
NOTE: You can also use the CURSOR button to select a parameter and the buttons to step
through the selected parameter’s available options. To exit a parameter, simply press CURSOR again.
CONTROL MENU PARAMETERS
MOD WHEEL
This parameter sets the modulation depth caused when the MODULATION wheel is raised to its
maximum position. The values range from -100% to +100%.
VELOCITY
This parameter sets the modulation depth caused when the keyboard velocity is played at its fastest
speed. The values range from -100% to +100%.
AFTERTOUCH
This parameter sets the modulation depth caused when the keyboard aftertouch is pressed fully. The
values range from -100% to +100%.
CTRL4 AMT
This parameter sets the modulation depth caused when a designated external MIDI CC (currently
fixed as CC#2) or other CTRL4 SRC is sent to the Sub 37. The values range from -100% to +100%.
CTRL4 SRC
This parameter allows you to choose the source of the fourth modulation depth controller. It had been
previously fixed to CC#2 BREATH, but can now also be assigned to FLT EG (Filter EG), AMP EG, LFO 1, or
LFO 2. If you choose FLT EG as the source, you can set the EG’s DELAY parameter to receive a delayed
LFO onset, for example.
MOD (1 OR 2) EDIT
Highlight MOD (1 OR 2) EDIT >> and press the CURSOR button to enter the MOD EDIT sub menu.
PGM SRC
This parameter allows you to change the MOD’s sixth modulation source from FILTER EG to:
AMP EG: Amplitude Envelope Generator CONST ON: Constant On
SINE LFO: Extra Sine Wave LFO NOISE LFO: Extra Noise LFO
OSC1 PCH: Oscillator 1’s Pitch OSC2 PCH: Oscillator 2’s Pitch
SEQ NOTE: Current Note of the Sequencer SEQ VEL: Current Velocity of the Sequencer
SEQ MOD: Mod Wheel Amount Stored In PRESSURE: Current Aftertouch Amount
Sequence Step KB TRACK: The current Key Tracking value
VELOCITY: Latest Note On velocity (bi-polar, centered on MIDI Note 48, Middle C)
MOD x CONTROL
MOD WHEEL: -100%...OFF..+100%
VELOCITY: -100%...OFF...+100%
AFTERTOUCH: -100%...OFF...+100%
CTRL4 AMT: -100%...OFF...+100%
CTRL4 SRC: BREATH, FLT EG,
AMP EG, LFO 1, LFO2
MOD x EDIT >>
1
MOD BUS x
PGM SRC: (See MOD PGM SRC list)
PGM DST: (See MOD PGM DST list)
LFO K
SWING LFO: OFF, ON
BTRACK: OFF...100%
