8-4 Maintenance: Recommended Test Tools
To replace the shield:
1. Add solder to the shield if necessary, using a micro-tipped soldering iron.
2. Next, rub the soldering iron tip along the edge of the shield to smooth out any excess solder.
Use solder wick and a soldering iron to remove excess solder from the solder pads on the
circuit board.
3. Place the circuit board back in the R1070’s circuit board holder.
4. Place the shield on the circuit board using a pair of tweezers.
5. Position the heat-focus head over the shield and lower it to approximately 1/8” (0.3 cm) above
the shield.
6. Turn on the heater and wait for the solder to reflow.
7. Once complete, turn off the heat, raise the heat-focus head and wait approximately one
minute for the part to cool.
8. Remove the circuit board and inspect the repair. No cleaning should be necessary.
8.6 Recommended Test Tools
Table 8-1 lists the recommended tools used for maintaining this family of radios. These tools are also
available from Motorola.
Table 8-1. Recommended Test Tools
Motorola Part
Number
Description Application
RSX4043 Torx Driver Tighten and remove chassis screws.
6680387A70 T-6 Torx Bit Removable Torx driver bit.
R1453A Digital readout solder station Digitally controlled soldering iron.
0180386A78 Illuminated magnifying glass
with lens attachment.
0180386A82
6684253C72
6680384A98
1010041A86
1080303E45
Anti-static grounding kit
Straight prober
Brush
Solder (RMA type),
63/37, 0.5mm diameter
1 lb. spool
SMD tool kit (included with
R1319A)
Used during all radio assembly and disassembly
procedures.
R1319A (110V)
or R1321A(220V)
ChipMaster Surface Mount
Rework Station
Removal and assembly of surface-mounted
integrated circuits and shields includes 5 nozzles.
R1364A Digital Heated Tweezer
System
Chip component removal.
R1427A Board Preheater Reduces heatsink on multi level boards.
8880309B53 Rework Equipment Catalog Contains application notes, procedures and technical
rework equipment.
