MSI A320M PRO-VD PLUS User Manual

10
󱭬󱝾󶯰󸊳
SATA1~4: SATA 6Gb/s 󳱥󲵑
󸶰󱛪󳱥󲵑󴂞 SATA 6Gb/s 󱜾󹪸󸷏󳰛󲘸󾗘󴪇󱤱󳱥󲵑󵵝󱿔󸷏󳰛󱘈󱤱 SATA 󸄅 󶷉󾗘
SATA1
SATA2
SATA3
SATA4
󹄟󸉕
y SATA 󳯷󶬢󱘗󱿔󳶒󵭶󸤥󸸶 90 󳍿󾗚󱝤󱭾󱩥󸯳󸠜󳾓󴂹󵫕󵫑󹏌󸑱󾗘
y SATA 󳯷󶬢󱮮󶔏󳰛󹰈󲡌󸊻󵸒󱟣󾗚󳐫󸘟󲻀󳌣󹰈󶔏󳰛󱳭󱙛󴟆󴋃󾗚󱝤󶚰󵸢󶐁󹞇󾗘
JFP1, JFP2: 󶥛󶩂󹪸󴋃󳰛󹰈
󸶰󱛪󳰛󹰈󵫞󳿕󸷏󳰛󱴚󹪸󴋃󵵙󹝻󹠁󲃅 LED 󳬙󶆻󵓻󾗘
1
2 10
9
JFP1
1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
HDD LED
RESET SW
HDD LED
HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
JFP1

MSI A320M PRO-VD PLUS Specifications

General

Form Factor	Micro ATX
Chipset	AMD A320
CPU Socket	AM4
Memory Slots	2 x DIMM
Maximum Memory	32GB
Storage Interface	4 x SATA 6Gb/s
LAN	Realtek 8111H Gigabit LAN
Memory Speed	DDR4 3200+(OC) MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	6 x USB 2.0 (2 rear, 4 front)
Audio	Realtek ALC887, 7.1-Channel High Definition Audio
Video Outputs	1 x VGA
