MSI A320M PRO-VD PLUS User Manual

15
󱭬󱝾󶯰󸊳 󱭬󱝾󶯰󸊳
JAUD1: 󱴚󶷉󹮪󳼋󳱥󲵑
󴉆󳱥󲵑󵫞󳿕󸷏󳰛󱴚󹪸󴋃󵵙󹮪󸌾󳱥󲵑󾗘
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection
JCOM1~2: 󳍙󱳋󲘸󳰛󹰈
󸶰󱛪󳰛󹰈󵫞󱡖󸷏󳰛󸺨󳸖󳘮󹀣󶷉󵵙󳍙󱳋󲘸󳨐󴌛󾗘
1
2 10
9
1 DCD 2 SIN
3 SOUT 4 DTR
5 Ground 6 DSR
7 RTS 8 CTS
9 RI 10 No Pin
JLED1: LED 󵓻󴒎󳰛󹰈
󳜂󱿔󸶕󸸶󴦞󳰛󹰈󸷏󳰛󲊓󷐡 LED 󵓻 󴒎󾗘
󹄟󸉕
y 󴉆󳰛󹰈󳻦󳲣 5050 󲊓󷐡 LED 󵓻󴒎󴇴󲡱󹰺󲷢󱶧󵠈󵋡 3A (12V)󾗘 󸒿󱣤󳬑 LED 󵓻󴒎󵾫󳿕 2
󶠽, 󱝤󹡩󴦛 LED 󵓻󱭶󱜏󳍿󴸟󳒔󾗘
y 󲶿󸄅󳦕󳫌󹢲 LED 󵓻󴒎󱴚󾗚󸒿󱭴󹠁󳯩󹧗󴻣󱡹󳤑󲏝󾗚󱘼󲻀󹧗󴻣󶬢󵫬󳱥󳎁󶌖󹢲󾗘
y 󸒿󱡋󵫞 MYSTIC LIGHT 󳰟󱳷󳹮󱭰 LED 󵓻 󴒎󾗘
1
1 +12V 2 NC
3 Signal 4 NC
1
JLED1
5050 LED 󵓻󴒎

MSI A320M PRO-VD PLUS Specifications

General

Form Factor	Micro ATX
Chipset	AMD A320
CPU Socket	AM4
Memory Slots	2 x DIMM
Maximum Memory	32GB
Storage Interface	4 x SATA 6Gb/s
LAN	Realtek 8111H Gigabit LAN
Memory Speed	DDR4 3200+(OC) MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	6 x USB 2.0 (2 rear, 4 front)
Audio	Realtek ALC887, 7.1-Channel High Definition Audio
Video Outputs	1 x VGA
