JAUD1: 󼕳󻟣 󽂗󺹿 󼎓󻊃󼎓 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻛫 󻸛󼐘󽋇󼍛 󼕳󻟣 󽂗󺹿󼓇 󼎓󻊃󼎓 󼔜󼒳 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection
JCOM1~2: 󼁋󻜛󼌫 󽅛󽀧 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󼌿 󻭻󻔇󼸦󼒳 󻸛󼐘󽋇󼍛 󼎤󻻇󼓧 󼁋󻜛󼌫 󽅛󽀧󻛫 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
1
2 10
9
1 DCD 2 SIN
3 SOUT 4 DTR
5 Ground 6 DSR
7 RTS 8 CTS
9 RI 10 No Pin
JLED1: LED 󼀓󽀧󻜬 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻛫 󻸛󼐘󽋇󼍛 󼁠󺭯 󼱛󻕛 LED 󼀓󽀧󻜬󼒳 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
󼚀󼐃󻸛󽋜
y 󼓣 󼱓󺺔󼺟󻀃 󼫋󻁯 3A (12V) 󼖄󺨘 󼕳󻖔󼌿󻺋 5050 󼁠󺭯 󼱛󻕛 LED 󼀓󽀧󻜬󼒳 󼜯󼐿󽋘󻀷󻁓. LED
󻦌󺮟󺥯 󼋬󽋣󼜷 󻾇 󼓷󼒫󻤯󻗋 󼀓󽀧󻜬󼓇 󺮧󼓣󺥯 2m󻩣󻁓 󼔀󼊳󼋫 󽋘󻀷󻁓.
y LED 󼀓󽀧󻜬󼒳 󻺓󼯇 󻍿󻀃 󼖋󺧟󽋇󺮟 󼕳󼌿 󽋜󻸰 󼕳󼐿 󺩤󺭸 󼔔󼯇󼓇 󼕳󼐿󼒳 󺶳󺩏 󼕳󼐿 󼳃󻉋󻛫
󼳇󻺫󽀧󼌿󻺋 󻳀󼊳󼙫󻺧󼐃.
y MYSTIC LIGHT󻛫 󻸛󼐘󽋇󼍛 󽏄󼔔󻆋 LED 󼀓󽀧󻜬󼒳 󼖋󼌣󽋇󻺧󼐃.
1
1 +12V 2 NC
3 Signal 4 NC
1
JLED1
5050 LED 󼀓󽀧󻜬

MSI A320M PRO-VD PLUS Specifications

General

Form Factor	Micro ATX
Chipset	AMD A320
CPU Socket	AM4
Memory Slots	2 x DIMM
Maximum Memory	32GB
Storage Interface	4 x SATA 6Gb/s
LAN	Realtek 8111H Gigabit LAN
Memory Speed	DDR4 3200+(OC) MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	6 x USB 2.0 (2 rear, 4 front)
Audio	Realtek ALC887, 7.1-Channel High Definition Audio
Video Outputs	1 x VGA
