MSI A320M PRO-VD PLUS User Manual

3
Safety Information Specifications
Specifications
CPU
Supports AMD
®
RYZEN series processors and 7th Gen
A-series/ Athlon™ processors for Socket AM4
Chipset
AMD
®
B350 chipset (B350M PRO-VD PLUS)
AMD
®
A320 chipset (A320M PRO-VD PLUS)
Memory
y 2x DDR4 memory slots, support up to 32GB
 Supports DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/
3200(OC)+ MHz*
y
Dual channel memory architecture
y
Supports ECC UDIMM memory (non-ECC mode)
y
Support non-ECC UDIMM memory
* 7th Gen A-series/ Athlon ™ processors support up to 2400
MHz only. Please refer www.msi.com for more information
on compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot
 RYZEN series processors support x16 mode
 7th Gen A-series/ Athlon™ processors support x8 mode
y 2x PCIe 3.0 x1 slots
Onboard Graphics
y 1x VGA port, supports a maximum resolution of
2048x1280@60Hz, 1920x1200@60Hz*
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
* Only support when using a 7th Gen A-series/ Athlon ™
processor.
Storage
AMD
®
B350/ A320 Chipset
y 4x SATA 6Gb/s ports
 Supports RAID 0, RAID1 and RAID 10
Audio
y Realtek
®
ALC887 Codec
y 7.1-Channel High Definition Audio
LAN 1x Realtek
®
8111H Gigabit LAN controller
USB
AMD
®
B350/ A320 Chipset
y 2x USB 3.1 Gen1 (SuperSpeed USB) ports through the
internal USB 3.1 Gen1 connector
y 6x USB 2.0 (High-speed USB) ports (2 ports on the back
panel, 4 ports available through the internal USB connectors)
AMD
®
processor
y 4x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the
back panel
Continued on next page

MSI A320M PRO-VD PLUS Specifications

General

Form Factor	Micro ATX
Chipset	AMD A320
CPU Socket	AM4
Memory Slots	2 x DIMM
Maximum Memory	32GB
Storage Interface	4 x SATA 6Gb/s
LAN	Realtek 8111H Gigabit LAN
Memory Speed	DDR4 3200+(OC) MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	6 x USB 2.0 (2 rear, 4 front)
Audio	Realtek ALC887, 7.1-Channel High Definition Audio
Video Outputs	1 x VGA
