1-8
MS-6421 Media Center
System Air Flow Direction
After the installation is completed, please keep
other objects away from the ventilation hole at
least 2.5cm and above. Do not block the ventila-
tion hole.
Ventilation Hole
(for Power Supply Fan)
Ventilation Hole
(for CPU Fan)
Ventilation
Hole (for ODD)
Ventilation
Hole (for HDD)
Front Panel
Back Panel
