MSI Z170A GAMING M7 User Manual

47
LED Status Indicators
Debug Code LED Table
Post Status
02,07 Power on CPU Initialization
03,08 Power on North Bridge Initialization
04,09 Power on South Bridge Initialization
0B Power on Cache Initialization
11~14,32~36,56~5A Early CPU Initialization
15~18,37~3A Early North Bridge Initialization
19~1C,3B~3E Early South Bridge Initialization
1D~2F,31,3F~4E,50~55 Early Memory Initialization
63~67,D0 Late CPU Initialization
69~6F,D1 Late North Bridge Initialization
70~77,D2 Late South Bridge Initialization
92~96,B5,D4 PCI bus Initialization
97,98,99,B2,D5~D7
Console Output/Input devices/Console initialization and
Load Option ROM (VGA, RAID, parallel ports, serial
ports……)
9A~A7,B4
Onboard devices Initialize and Detect (USB/ SATA/
SCSI……)
A8,A9,AB Start of Setup. BIOS setup if needed/ requested.
AD/AE Ready To Boot event/Legacy Boot event
CPU temperature Fully boot

MSI Z170A GAMING M7 Specifications

General

Chipset	Intel Z170
CPU Socket	LGA 1151
Memory Slots	4 x DIMM
Maximum Memory	64GB
Form Factor	ATX
Audio	Realtek ALC1150
M.2 Slots	1
USB 3.1 Gen1 Ports	8
PCI Express x16 Slots	3
PCI Express x1 Slots	4
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD 3-Way CrossFire, NVIDIA 2-Way SLI
Storage Interface	6 x SATA 6Gb/s
USB Ports	8 x USB 3.1 Gen1
LAN	Killer E2400 Gigabit LAN Controller
