Temposonics
®
E-Series CANopen
Operation Manual
40
8. Technical data
4/ EP/EL: With position magnet #252 182; EH: With position magnet #251 416-2
5/ The IP rating is not part of the UL approval
6/ EP/EL: The IP rating is valid for the sensor electronics only
Output
Interface CAN System ISO-11898
Data protocol CANopen: CIA Standard DS 301 V3.0 / Encoder Profile DS 406 V3.1
Baud rate, kBit/s 1000 800 500 250 125
Cable length, m
< 25 < 50 < 100 < 250 < 500
The sensor will be supplied with ordered baud rate, changeable by customer via LSS
Measured value Position
Measurement parameters
Resolution 10 µm, 20 µm
Cycle time 1 ms
Linearity
3
≤ ±0.02 % F.S. (minimum ±60 µm)
Repeatability ≤ ±0.005 % F.S. (minimum ±20 µm)
Operating conditions
Operating temperature −40…+75 °C (−40…+167 °F)
Humidity 90 % rel. humidity, no condensation
Ingress protection
4
EP
5
/EL
5
/EH: IP67 with proper mating connector
EH: IP69K with proper mating connector
Shock test 100 g (single shock) IEC standard 60068-2-27
Vibration test 15 g / 10…2000 Hz IEC standard 60068-2-6 (resonance frequencies excluded)
EMC test Electromagnetic emission according to EN 61000-6-4
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
.
Magnet movement velocity
Ring & U-magnets: Any
Magnet sliders: 10 m/s
Design/Material
Sensor electronics housing (EP/EL) Aluminum
Sensor profile (EP/EL) Aluminum
Sensor electronics housing (EH) Stainless steel 1.4305 (AISI 303); Option: 1.4404 (AISI 316L)
Sensor rod (EH)
Rod Ø 7 mm (0.28 in.): Stainless steel 1.4301 (AISI 304)
Rod Ø 10 mm (0.39 in.): Stainless steel 1.4306 (AISI 304L);
Option: Stainless steel 1.4404 (AISI 316L)
Stroke length 50 …2540 mm (2…100 in.)
Operating pressure (EH) Rod Ø 7 mm (0.28 in.): 300 bar (4351 psi), 450 bar (6527 psi) peak
Rod Ø 10 mm (0.39 in.): 350 bar (5076 psi), 530 bar (7687 psi) peak
Mechanical mounting
Mounting position Any
