National Instruments PCIe-6323 User Manual

© National Instruments | A-15
X Series User Manual
Figure A-10. NI USB 6346 Screw Terminal Pinout
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
AI 4+
AI 4–
AI GND
AI 5+
AI 5–
AI GND
AI 6+
AI 6–
AI GND
AI 7+
AI 7–
AI GND
APFI 0
AI GND
AO 1
AO GND
AI 0+
AI 0–
AI GND
AI 1+
AI 1–
AI GND
AI 2+
AI 2–
AI GND
AI 3+
AI 3–
AI GND
RESERVED
AI GND
AO 0
AO GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
PFI 8/P2.0
D GND
PFI 9/P2.1
D GND
PFI 10/P2.2
D GND
PFI 11/P2.3
D GND
PFI 12/P2.4
D GND
PFI 13/P2.5
D GND
PFI 14/P2.6
D GND
PFI 15/P2.7
+5 V
P0.0
P0.1
P0.2
P0.3
P0.4
P0.5
P0.6
P0.7
PFI 0/P1.0
PFI 1/P1.1
PFI 2/P1.2
PFI 3/P1.3
PFI 4/P1.4
PFI 5/P1.5
PFI 6/P1.6
PFI 7/P1.7
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
