Chapter 3 I/O Information
NI PXI-8109 User Manual 3-12 ni.com
ExpressCard/34 Slot
The NI PXI-8109 controller is equipped with an ExpressCard/34 slot on the
front panel, which provides I/O expansion and options for removable
storage, Ethernet, and a variety of other I/O.
Figure 3-9 shows the location and pinouts for the ExpressCard/34 slot on
the NI PXI-8109. Table 3-10 lists and describes the ExpressCard connector
signals.
Figure 3-9. ExpressCard/34 Slot Location and Pinout
11 ATN# Attention
12 SHIELD Chassis ground
13 DIO5# Data Bit 5
14 DIO6# Data Bit 6
15 DIO7# Data Bit 7
16 DIO8# Data Bit 8
17 REN# Remote Enable
18–25 GND Logic Ground
Table 3-9. GPIB Connector Signals (Continued)
Pin Signal Name Signal Description
1
ExpressCard/34 Slot
26
NI PXI-8109
Embedded Controller
