English-42
USB
TOUCH POWER
(Not available)
EXTERNAL CONTROL When ON is set, the monitor is controlled by a device installed particular software which is connected to USB2.
PC SOURCE Select a device connected to USB1 which controls the monitor. If a control device is specifi c, select EXTERNAL
PC or OPTION.
OPTION is only available when slot 2 type PC option is connected to the monitor.
USB POWER Selects a power relation of USB CM1 (2A).
Set ON to supply the power to the USB CM1 (2A).
NOTE: Power consumption depends on which USB devices are connected to the monitor.
CEC* This function enables you to control the HDMI CEC compliant device connected via HDMI connector.
*: CEC is an abbreviation of Consumer Electronics Control.
CEC When ON is set, please set items below.
NOTE: If ON is selected, the below functions are activated.
When the connected HDMI CEC device receives play command, the monitor synchronously turns on then
changes the input signal to HDMI. If the monitor has been turned on, when connected HDMI CEC device
received a play command, input signal is switched to HDMI.
The connected HDMI CEC devices are controlled by the wireless remote control supplied with the monitor.
Depending on the connected device, sometimes the device does not work properly.
AUTO TURN OFF When the monitor goes to standby via remote control or the power button on the monitor, connected HDMI CEC
device go to standby synchronously.
NOTE: If the connected HDMI CEC device is recording, the device does not go into standby.
AUDIO RECEIVER Activates HDMI CEC audio amplifi er. If YES is set, outputs the sounds of the connected HDMI CEC device from
the connected HDMI CEC audio amplifi er. If YES is set, the internal speaker or the external speaker connected to
the monitor is set to mute.
NOTE: When a HDMI CEC audio amplifi er is connected, set to YES.
Please set to NO if there is no connecting HDMI CEC audio device to the monitor.
SEARCH DEVICE Searches the HDMI CEC device connected to the monitor. When search is success, the connected HDMI CEC
device’s type and registered device name are shown. When search has been completed or failed, the SEARCH
DEVICE is set to NO automatically. To retry the SEARCH DEVICE, set it to YES again. After detected HDMI CEC
devices, you can switch the device input by selecting the device.
RESET Resets all the settings within the CONTROL menu back to factory setting except for LAN, CHANGE
PASSWORD, SECURITY, PING and INTELLI. WIRELESS DATA.
OPTION
AUDIO*
1
Selects sound input signal according to slot2 type option’s specifi cations. To activate DIGITAL, select OPTION for
input signal and OPTION for AUDIO INPUT.
NOTE: DIGITAL is activated only when OPTION is selected for input signal and OPTION for AUDIO INPUT.
INTERNAL PC*
1
The function is available for slot 2 type PC.
OFF WARNING
(Not adjustable)
AUTO OFF Monitor power is automatically on standby when connected slot 2 type PC is OFF or the monitor is in power save
mode.
NOTE: If you select “OFF”, monitor power is not automatically turned “ON” when connected slot 2 type PC is
turned ON.
START UP PC When ON is selected, connected slot 2 type PC start-up.
FORCE QUIT When ON is selected, it performs force-quit slot 2 type PC.
Please use this function only when the operating system cannot be shut down manually.
SLOT2 CH SETTING Selects signal type according to slot 2 type option’s specifi cations.
AUTO Sets signal type automatically.
1CH Fills entire the signal, which is selected in SLOT2 CH SELECT.
2CH DisplayPort signal is displayed in the left half, TMDS signal is displayed in the right half. If you do not have either
of the input signal, the signal having the input is automatically displayed on the full screen.
SLOT2 CH SELECT This function is available only when SLOT2 CH SETTING is 1CH.
DisplayPort Shows the DisplayPort signal from slot 2 type PC option into full entire screen.
TMDS Shows the TMDS signal from slot 2 type PC option into full entire screen.
RESET Resets the AUDIO setting back to the factory setting within the OPTION menu.
*1: This function depends on which option board you use. When changing the setting, turn the monitor’s main power switch off and on again.
To Next Page
