NetComm Wireless NF8AC User Guide
Advanced Setup
Layer2 Interface
ATM Interface
The ATM (Asynchronous Transfer Mode) interface page shows the settings of all available DSL ATM interfaces.
This field shows the interface name.
This field shows the Virtual Path Identifier (VPI) value. For most Australia connections the VPI is 8, for
most new Zealand connections the VPI is 0.
This field shows the Virtual Channel Identifier (VCI) value. For most Australia connections the VCI is 35,
for most new Zealand connections the VCI is 100.
The value of the DSL Latency.
This field shows the ATM service classes.
The maximum number of cells that may be transferred per second over the ATM interface.
Sustainable Cell Rate (cell/s)
An average, long-term cell transfer rate on the ATM interface.
The maximum allowable burst size of cells that can be transmitted contiguously on the ATM interface.
The minimum allowable rate at which cells may be transferred on the ATM interface.
This field shows the type of link in use.
This field shows the selected mode of connection.
This field shows the status of the Quality of Service (QoS) function.
This displays data related to load balancing.
Select this field to remove the ATM configuration.
To add an ATM interface, click the Add button. Enter the details as required by your Internet Service Provider and click the
Apply/Save button.
