NetComm Wireless NF8AC User Guide
IPv4inIPv6
Figure 32: Advanced - IP Tunnel – IPv4inIPv6
Click the Add button to add a new tunnel.
Figure 33: Advanced - IP Tunnel – IPv4inIPv6 - 4in6 Tunnel Configuration
IPSec
The NF8AC offers IPSec VPN tunnel functionality. To delete an IPSec entry, click the Remove checkbox next to the selected IPSec
tunnel entry and click Remove.
Click Add to create a new IPSec tunnel connection.
Figure 34: Advanced - IPSec
Enter the following parameters:
Enter a name to identify the IPSec tunnel
Select the applicable IPSec tunnel mode
Enter the IP Address of the IPSec server to connect to
Select which remote addresses local IPSec connections are able to access
Enter the IP Address to be used locally for the IPSec tunnel
Enter the subnet mask to be used locally for the IPSec tunnel
Tunnel Access from Remote
Select which local addresses remote IPSec connections are able to access
Enter the IP Address to be used on the remote end for the IPSec tunnel
Enter the subnet mask to be used on the remote end for the IPSec tunnel
Select the type of IPSec exchange is to be used on the IPSec tunnel
Select the applicable authentication for the IPSec tunnel
Enter the pre-shared key (if applicable) to grant access to the IPSec tunnel
Select to use Perfect Forward Secrecy during key exchange for the IPSec tunnel
Configure advanced IKE settings for the IPSec tunnel such as the encryption method or key life time
After entering the required IPSec tunnel service settings, click Apply/Save to save the new IPSec Tunnel configuration settings.
