6.7.3 - Memorization of transmitter in Mode 2
In this mode, each transmitter key can be associated with one of the
15 possible control unit commands shown in Table 14; Only one key is
memorised for each stage, namely the one which was pressed during
memorisation. One place in the memory is occupied for each key
memorised.
Table 14 - Commands available in Mode 2
Command 1 “Step by Step”
Command 2 “Partial opening”
Command 3 “Open”
Command 4 “Close”
Command 5 “Stop”
Command 6 “Condominium Step by Step”
Command 7 “Step by Step High priority”
Command 8 “Open and unlock”
Command 9 “Close and unlock”
Command 10 “Open and Lock automation”
Command 11 “Close and Lock automation”
Command 12 “Lock automation”
Command 13 “Release automation”
Command 14 “Timer On Courtesy light”
Command 15 “Courtesy light On-Off”
6.7.4 -Procedure for Mode 2 memorisation
Table 15 - Procedure to memorize the key of a transmitter in mode 2
01. Press the key on the receiver as many times as the number corresponding to the desired command,
according to table 14
1....4
02. Make sure that the LED on the receiver makes as many flashes as the number corresponding to the se-
lected command
1....4
03. Within 10 s, press any key on the radio transmitter to be memorized and hold it down for at least 2 s
3S
04. The LED on the receiver will flash 3 times if the memorization procedure has been successful.
X3
If there are other transmitters to be memorized for the same type of command,
repeat step 3 within the next 10 s, otherwise the memorization stage will terminate automatically.
6.8 - “Remote” memorization
the keys on the receiver. You need to have a pre-memorized operational radio transmitter The “new” radio transmitter will inherit the characteri-
stics of the old one, i.e. if the old radio transmitter was memorized in Mode 1, the new one will also be memorized in Mode 1. In this case, during
the memorization stage you can press any key on the two transmitters. If, on the other hand, the old transmitter was memorized in Mode 2, the
new one will also be memorized in Mode 2: you must press the key on the old transmitter which corresponds to the desired command, and the
key on the new transmitter to which you wish to associate that command.
Remote memorisation can occur in all those receivers which are within range of the capacity of the transmitter.
Therefore, only the one which is actually involved in the operation must be powered.
Holding the two transmitters, position yourself within the operating range of the automation and perform the following operations:
Table 16 - for the “Remote” memorization of a transmitter
01. Press the key on the new radio transmitter and hold it down for at least 5 s, then release it.
8S
02. Press key on the previously memorized transmitter slowly 3 times.
3S 3S 3S
03. Press the key on the new radio transmitter once slowly.
1S
At this point the new radio transmitter will be recognized by the receiver and will assume the characteristics of the previously memorized one.
If there are other transmitters to be memorized, repeat all the steps above for each new transmitter.
