Nice UST1-FU User Manual

EN
English – 5
Jumpers and U-bolts necessary for control unit
operation with components not connected
Jumpers: U-bolts:
X2-J10 X8-Pin 5-6
X4-J15 X9-Pin 1-2
X5-J31 8.2kΩ-Pin 1-2
X6-J33 Opto-Pin 2-3
Additional electronic limit switch X7- J26, J27, J28
ATTENTION: It is recommended to also install module K5
(optional) on the main board for adjustment. See the K5
module instructions for more details.

Nice UST1-FU Specifications

General

Brand	Nice
Model	UST1-FU
Category	Control Unit
Language	English
