EN
English – 13
TECHNICAL DATA - FEATURES
WARNINGS
• All of the technical characteristics indicated refer to a temperature of 20°C (± 5°C).
• Nice reserves the right to introduce all modications to the product it deems necessary at any time, however keeping the functions and intended use
unaltered.
UST1-FU
DESCRIPTION DATA
Voltage power supply: 1 x 230V AC 50Hz (10A protection)
3 x 400V AC 50Hz (16A protection)
Connecting the motor via inverter: see the table below
Power at rest: < 4VA
Ambient temperature: from -10°C to +50°C
Control voltage: Additional delayed 0.8A fuse
Protection rating: IP 54 (IP 65 optional)
Dimensions: 255 x 180 x 120mm (HxWxD)
0.37 KW 0.75 KW - INVERTER 3 Phases – 230V
0.55 KW 0.75 KW - INVERTER 3 Phases – 230V
1.5 KW 2.2 KW –INVERTER 3 Phases – 230V
2.2 KW 3 KW – INVERTER 3 Phases – 400V
0.75 KW 1.5 KW – INVERTER 3 Phases – 230V
1.1 KW 2.2 KW – INVERTER 3 Phases – 230V
HDF – INVERTER TABLE
MOTOR
INVERTER MOTOR VOLTAGE
The control unit is totally assembled and wired, ready for connection.
The control unit is to be kept inside its packaging during transport and storage, if any, to prevent damage.
For disposal, it is necessary to separate
− metals
− plastic elements
− electrical components
− lubricants.
TRANSPORT / STORAGE / DISPOSAL
TECHNICAL ASSISTANCE / SPARE PARTS / ACCESSORIES
We specically clarify that we neither carry out tests nor are we willing to approve any spare parts and/or accessories not
supplied by us.
The assembly and/or use of products of this type could jeopardise gearmotor features pre-dened at the construction level,
which can reect on safety.
NICE declines all responsibility and disclaims any warranty whatsoever for damages, if any, caused by using non-original
spare parts and/or accessories.
Defects that cannot be remedied internally are to be eliminated only by the door manufacturer or another specialised
company, from which it is possible to also request any necessary spare parts.
