VBA10201-R.3577.A
- Ａ16 ･ -
SQ FPC
SHUTTER
1. Mirror up
Green：SQ Motor
Orange：SQ Motor
ＳＱ ＦＰＣ
B91
#734x2
Tighten the screw#732 to x
the SQ FPC.
● Turn the white gear of the SQ unit
in the arrow direction to stand up the
mirror.
