Names of Parts
1
This microscope consists of the parts shown in the figure below.
*1 This photo shows an example of ECLIPSE TS100-F with ELWD condenser.
*2 The light source for ECLIPSE TS100/TS100-F is halogen lamp, and the light source for
ECLIPSE TS100LED MV/TS100LED-F MV is white LED.
*3 ECLIPSE TS100LED MV/TS100LED-F MV is designed for AC power of 100 to 240 V AC and
50/60 Hz, thus has no fuse.
Lamp
*2
Lamphouse
Stage
Condenser
Objective
Revolving nosepiece
Fuse
*3
Power cord
Main body
*1
Eyepiece tube
Eyepiece
