Lamp
CAUTION
The lamp and the surrounding area become very hot
during and immediately after using the illuminator.
Be careful not to burn yourself. In addition, be sure
the lamp has cooled sufficiently before replacing a
lamp.
Pull the lamp socket from the lamp house and
insert the lamp straight into the socket as far
as it will go. Only use halogen lamps of the
specified rating.
Next, attach the lamp socket to the lamp
house.
C-DSLS
Note) Do not touch the glass part of a lamp with your bare hands as your
skin may burn and stick to the lamp, possibly reducing its level of
light output or causing damage to the lamp. When replacing a
Socket
Lamp
(GE 787 6V-10W)
Socket Short protrusion
Holder mounting
screw hole
Light
shielding tube
Lamp
(Philips JCR/M
6V-20W)
Confirmation
window
G-LS
