Table 1: Total Magnification and Real Field
SMZ800
Eyepieces
Working
10 X 15 X 20 X 30 X
distance
Field number 22 Field number 16 Field number 12.5 Field number 7
Objectives [mm] Reticle diameter ø25 Reticle diameter ø19 Reticle diameter ø19 Reticle diameter ø12
Magnification 1.3X Magnification 1.4X
Total Real field Total Real field Total Real field Total Real field
magnification [mm] magnification [mm] magnification [mm] magnification [mm]
Acro 0.5 X 189 5.0 ~ 31.5 X 44.0 ~ 7.0 7.5 ~ 47.3 X 32.0 ~ 5.1 10.0 ~ 63.0 X 25.0 ~ 4.0 15.0 ~ 94.5 X 14.0 ~ 2.2
Plan 1 X 78 10.0 ~ 63.0 X 22.0 ~ 3.5 15.0 ~ 94.5 X 16.0 ~ 2.5 20.0 ~ 126.0 X 12.5 ~ 2.0 30.0 ~ 189.0 X 7.0 ~ 1.1
Plan 1 X ERGO 50 10.0 ~ 63.0 X 22.0 ~ 3.5 15.0 ~ 94.5 X 16.0 ~ 2.5 20.0 ~ 126.0 X 12.5 ~ 2.0 30.0 ~ 189.0 X 7.0 ~ 1.1
Plan Apo 0.5 X 123 5.0 ~ 31.5 X 44.0 ~ 7.0 7.5 ~ 47.3 X 32.0 ~ 5.1 10.0 ~ 63.0 X 25.0 ~ 4.0 15.0 ~ 94.5 X 14.0 ~ 2.2
Plan Apo 1 X 70 10.0 ~ 63.0 X 22.0 ~ 3.5 15.0 ~ 94.5 X 16.0 ~ 2.5 20.0 ~ 126.0 X 12.5 ~ 2.0 30.0 ~ 189.0 X 7.0 ~ 1.1
ED Plan 1.5 X 44.5 15.0 ~ 94.5 X 14.7 ~ 2.3 22.5 ~ 141.8 X 10.7 ~ 1.7 30.0 ~ 189.0 X 8.3 ~ 1.3 45.0 ~ 283.5 X 4.7 ~ 0.7
ED Plan 2 X 32.5 20.0 ~ 126.0 X 11.0 ~ 1.7 30.0 ~ 189.0 X 8.0 ~ 1.3 40.0 ~ 252.0 X 6.3 ~ 1.0 60.0 ~ 378.0 X 3.5 ~ 0.6
HR Plan Apo 0.5 X 136 6.3 ~ 39.4 X 35.2 ~ 5.6 9.4 ~ 59.1 X 25.6 ~ 4.1 12.5 ~ 78.8 X 20.0 ~ 3.2 18.8 ~ 118.1 X 11.2 ~ 1.8
HR Plan Apo 1 X 54 12.5 ~ 78.8 X 17.6 ~ 2.8 18.8 ~ 118.1 X 12.8 ~ 2.0 25.0 ~ 157.5 X 10.0 ~ 1.6 37.5 ~ 236.3 X 5.6 ~ 0.9
HR Plan Apo 1.6 X 24 20.0 ~ 126.0 X 11.0 ~ 1.7 30.0 ~ 189.0 X 8.0 ~ 1.3 40.0 ~ 252.0 X 6.3 ~ 1.0 60.0 ~ 378.0 X 3.5 ~ 0.6
