Nikon SMZ800 User Manual

38
Table 2: Observable Sample Heights
Table 2: Observable Sample Heights [mm]
SMZ1000 + C-PS160 + C-FMC
Mount Mount up When using
When using
Objectives normal side down C-EP
SM-S4L
position position extension pillar
and C-EP
extension pillar
Acro 0.5X 0 ~ 24 — 0 ~ 124 0 ~ 13
Plan 1X 0 ~ 97 0 ~ 42 0 ~ 197 0 ~ 86
Plan 1X ERGO 0 ~ 114 0 ~ 59 0 ~ 214 0 ~ 103
Plan Apo 0.5X 0 ~ 25 — 0 ~ 125 0 ~ 14
Plan Apo 1X 0 ~ 102 0 ~ 47 0 ~ 202 0 ~ 91
ED Plan 1.5X 0 ~ 111 0 ~ 56 0 ~ 211 0 ~ 100
ED Plan 2X 0 ~ 108 0 ~ 53 0 ~ 208 0 ~ 97
HR Plan Apo 0.5X 0 ~ 33 — 0 ~ 133 0 ~ 22
HR Plan Apo 1X 0 ~ 103 0 ~ 48 0 ~ 203 0 ~ 92
HR Plan Apo 1.6X 0 ~ 112 0 ~ 57 0 ~ 212 0 ~ 101
SMZ800 + C-PS
Arm normal Arm lower When using
When using
Objectives
position position auxiliary adapter
SM-S4L and
auxiliary adapter
Acro 0.5X 0 ~ 2 — 0 ~ 58 —
Plan 1X 0 ~ 75 0 ~ 20 26 ~ 131 0 ~ 20
Plan 1X ERGO 0 ~ 92 0 ~ 37 3 ~ 148 0 ~ 37
Plan Apo 0.5X 0 ~ 3 — 0 ~ 59 —
Plan Apo 1X 0 ~ 81 0 ~ 26 32 ~ 137 0 ~ 25
ED Plan 1.5X 0 ~ 89 0 ~ 34 40 ~ 145 0 ~ 34
ED Plan 2X 0 ~ 87 0 ~ 32 38 ~ 143 0 ~ 31
HR Plan Apo 0.5X 0 ~ 11 — 0 ~ 67 —
HR Plan Apo 1X 0 ~ 82 0 ~ 27 33 ~ 138 0 ~ 27
HR Plan Apo 1.6X 0 ~ 90 0 ~ 35 41 ~ 146 0 ~ 35
