Show data
You can read off current operational data for the ventilation unit. This will allow you to check that the unit operates satisfactorily and
to identify the cause of potential alarms.
> Show data
> Compact P
> Operating state Description: Shows in which operating setting the unit is running.
> Bypass Description: Shows whether the bypass damper is open or closed.
> Anode Description: Shows whether the anode is in working order. If faulty, it must
be replaced.
> T1 Outdoor air Description: Shows the outdoor temperature before the pre-heating ele-
ment.
> T2 Supply air Description: Shows the supply air temperature.
> T4 Discharge Description: Shows the discharge air temperature.
> T5 Condenser Description: Shows the condenser temperature.
> T6 Evaporator Description: Shows the evaporator temperature.
> T10 Extract air/Room Description: Shows the current room temperature measured in the extract
air.
> T11 Top hot water Description: Shows the current temperature in the top of the hot water tank.
Controls the supplementary electric heating.
> T12 Bottom hot water Description: Shows the current temperature at the bottom of the hot water
tank.
> Humidity Description: Shows the current humidity level in the dwelling.
> CO
2
level Description: Shows the current CO
2
level in the dwelling (only if installed).
> Supply air fan Description: Shows the current fan speed level of the supply air fan.
> Extract air fan Description: Shows the current fan speed level of the extract air fan.
> Unit information Description: Press for further information about the ventilation unit.
> Unit type Description: Shows what type of ventilation unit it is.
> Software version Description: Shows the software version of the ventilation unit.
> Panel software Description: Shows the software version of the control panel.
> GEO
> Status Description: Shows in which operating setting the GEO is running.
> Anode SHW tank Description: Shows whether the anode is in working order, if an SHW tank
has been installed. If faulty, the anode must be replaced.
> T13 Return flow brine Description: Shows the current temperature of the return flow from the
ground.
> T14 Supply flow brine Description: Shows the current temperature of the supply flow to the
ground.
> T16 Return flow heating Description: Shows the current temperature of the return flow from the
central heating.
> T17 Supply flow heating Description: Shows the current temperature of the supply flow to the cen-
tral heating.
> T18 Buffer tank temperature Description: Shows the current temperature of the supply flow to the buffer
tank (only if installed).
> T20 Outdoor temperature Description: Shows the outdoor temperature measured in the outdoor air
duct in the ventilation system
> T21 SHW top temperature Description: Shows the current temperature in the top of the SHW tank (only
if installed).
