ENGLISH INSTRUCTION FOR USE
8 SC351 - 9099867000
TECHNICAL DATA
Description SC351
Solution tank capacity 2.9 USgal (11 liters)
Recovery tank capacity 2.9 USgal (11 liters)
Min/max machine length at the handlebar 31.9 in / 50 in (810 mm / 1270 mm)
Machine width 18.5 in (470 mm)
Min/max machine height with adjustable handlebar 550 / 1000 mm (21.6 / 39.4 in)
Minimum width for turnaround 33.5 in (850 mm)
Cleaning width 14.5 in (370 mm)
Diameter of wheels on xed axle 8.4 in (214 mm)
Wheel pressure on the oor 72.5 psi (0.5 N/mm
2
)
Brush/pad diameter 14.5 in (370 mm)
Brush/pad pressure on the oor 40 lb (18 Kg)
Brush/pad pressure with full tank 60 lb (27 Kg)
Min/max solution ow
One drop, “ECO”: 0.066 gpm (0.25 liters/min)
Two drops: 0.13 gpm (0,5 liters/min)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
65 dB(A) ± 3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72)
< 98.4 in/s
2
(< 2.5 m/s
2
)
Maximum gradient when working 2%
IP protection class
X4
Protection class (electric)
III
Vacuum system motor power 0.27 hp (200 W)
Vacuuming 27.7 in/H
2
O (710 mmH
2
O)
Brush/pad-holder motor power 0.35 hp (260 W)
Brush/pad-holder motor speed 120 rpm
Total absorbed power 42 A (0.5 kW)
Battery compartment size 17.8x6.9x9.4 in (350x175x240 mm)
Battery voltage 12 V
Standard battery 12V 84AhC5 AGM
Battery charger 100-240 VAC
Work autonomy (standard battery) 2 hour
Weight without battery and with empty tanks
95 lb (43 kg)
Gross vehicle weight (GVW) 176 lb (80 kg)
Shipping weight
172 lb (78 kg)
Machine material composition and recyclability
Type Recyclable
percentage
SC351 weight percentage
Aluminium 100% 18%
Electric motors - various 29% 9%
Ferrous materials 100% 20%
Wiring harness 80% 9%
Liquids 100% 0%
Plastic - non-recyclable material 0% 11%
Plastic - recyclable material 100% 18%
Polyethylene 92% 9%
Rubber 20% 7%
