ENGLISH INSTRUCTION FOR USE
16 SC351 - 9099867000
MACHINE SPEED ADJUSTMENT
NOTE
The machine speed varies according to the type of oor to be cleaned and the choice of using the brush or the pad.
If necessary, perform the adjustments as shown.
1. Remove the recovery and the detergent tanks.
2. Adjust the machine speed with the handwheel (A, Fig. 5):
• Turn the handwheel counter-clockwise to increase the machine speed.
• Turn the handwheel clockwise to decrease the machine speed.
3. If it is difcult to keep the machine moving straight-forwardly because it deviates to the left or to the right, adjust the handwheel
(B) by turning it clockwise or counter-clockwise.
4. After adjusting, install the tanks as shown in Use chapter.
5. With the machine ready to operate, perform hands-on tests of the machine and, if other adjustments are necessary, repeat
steps 1 to 4.
A
B
Figure 5
P100413
