Install an E-240G-B ONU
60
7368 ISAM ONT E-240G-B Product Guide
3FE-46261-AAAA-TCZZA Issue: 01
3 Mount the ONU as shown in Figure 20. If possible, mount the ONU on a wall stud.
Figure 20 Wall mounting keyholes on E-240G-B ONUs (without fiber
storage tray)
Note — If the Emerson 24W AC/DC Power Adapter, CyberPower CS27
UPS, or Delta DUPS-1232GA will be used, the ONU must be mounted a
minimum of 31.5 in (0.8 m) above the floor.
If the Delta DUPS-1232A will be used, the ONU must be mounted a
minimum of 59 in (1.5 m) above the floor.
RESET
Keyholes for horizontal mounting
Keyholes for
vertical
mounting
24111
Release 06.01.01 | June 2019 | Edition 09
