7368 ISAM ONT E-240G-B Product Guide Install an E-240G-B ONU
Issue: 01 3FE-46261-AAAA-TCZZA 67
Figure 25 Outdoor enclosure with fiber optic cable
6 Secure the E-240G-B ONU in the wall-mounted outdoor enclosure.
a Turn the brackets to the open position and position the E-240G-B ONU within the
outdoor enclosure and between the ONU brackets, as shown in Figure 24.
b Secure the E-240G-B ONU within the ONU brackets by turning the brackets to the
closed position.
7 Review the connection locations shown in Figure 19 for E-240G-B ONUs.
23703
Fiber
strain
relief
Fiber cable
Warning — Do not overtighten the ONU bracket when securing the
E-240G-B ONU to the outdoor enclosure. The ONU can become skewed
and compromise the environmental seal of the ONU mounted in the
outdoor enclosure.
Release 06.01.01 | June 2019 | Edition 09
