Nokia 7368 ISAM ONT E-240G-B User Manual

7368 ISAM ONT E-240G-B Product Guide Install an E-240G-B ONU
Issue: 01 3FE-46261-AAAA-TCZZA 63
4 Wall-mount the outdoor enclosure.
a If you are using a fiber-slack storage tray (FSST):
i Secure the FSST to the mounting area. Use the appropriate hardware as defined
by local installation practices. Use the cable storage compartment mounting holes;
see Figure 22.
Figure 22 Mounting the cable storage compartment (3EM 20293 AA)
ii Remove either the aerial or buried cable entry grommet; see Figure 23.
Note — The outdoor enclosure must be mounted a minimum of 59 in.
(1.5 m) above the floor.
Bracket mounting point Bracket mounting point
Cable storage compartment
mounting hole slot
Cable storage
compartment
mounting hole
Cable storage
compartment
mounting hole
19090
Bracket mounting point
Release 06.01.01 | June 2019 | Edition 09
